Neutrik NLT8FX-BAG Speakon 8-pole male chassis connector, black-chrome metal housing, solder or ¼" flat tabs

Artikelnummer: DON-NLT8FX-BAG

The speakON panel mount connectors are the standard chassis connectors for loudspeaker / amplifier interconnections. They feature a unique metal locking system, making contact only once fully locked. The speakON receptacles are robust, versatile and easy to terminate.

Kategorie: SpeakON Stecker


19,33 €

inkl. 19% USt., zzgl. Versand

Lieferung in 49 Tagen ab Bestellung

Lieferzeit: 51 - 52 Werktage



Beschreibung

The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series features an all metal housing.



Features & Benefits

  • Extremely robust metal housing designed for harsh and demanding environment
  • Ideal product for touring applications and harsh environments
  • Current rating 40 Amp continuous, 50 Amp audio signal with 50% duty cycle
  • Uses precise “Quick Lock” system
  • Mates with all currently available speakON products
Product
Title
NLT8FX-BAG
Connection Type
speakON
Gender
female
Electrical
Contact resistance
< 2 m? (inner) (after lifetime)
Dielectric strength
4 kVdc (peak)
Insulation resistance
> 10 G? (after dampheat)
Rated current per contact
40 A rms continuous
Rated current per contact
50 A audiosignal, duty cycle 50 %
Rated voltage
250 V (Insulation)
Attention
speakON is NOT to be used as an AC mains or power supply connector!
Mechanical
Cable O.D.
8 - 20 mm
Cable retention
? 220 N (subject to cable O.D. and material)
Lifetime
> 5000 mating cycles
Wiresize
6 mm²
Wiresize
10 AWG
Wiring
Solder contacts
Locking device
Quick Lock (latch)
Material
Contact plating
4 µm Ag
Contacts
Brass (CuZn39Pb3)
Insert
Polyamide (PA 6 30 % GR)
Locking element
Zinc diecast (ZnAl4Cu1)
Shell
Zinc diecast (ZnAl4Cu1)
Strain relief
Polyacetal (POM)
Environmental
Flammability
UL 94 HB
Protection class
IP 52 (mated condition)
Solderability
Complies with IEC 68-2-20
Temperature range
-30 °C to +80 °C

Material: Metall
Versandgewicht: 0,10 Kg
